• 14x30W RGB LED(Pixel).
• Mounting brackets allow fixture to be flown or floor-mounted.
• Rugged die-cast body and touring-grade construction.
• Color and white presets available via onboard menu or DMX.
• Silent operation with advanced fan-less thermal management.
• Onboard library of 14 dynamic preprogrammed light shows.
• Custom color mixing and adjustable white balance.
• Menu display backlight auto blackout.
• Power linking (IP65 Power In/Out).
Optical:
• 14x30W RGB 3in1 LED (Pixel)
• LED Life Expectancy: 50,000 Hrs
• Refresh Rate: 3.6KHz
• Angle: 22°
• Highly efficient lens system
Technical Features:
• 63 Built In Color Macros
• 5 Operational Modes: Manual Color; Color Fade; Auto Program; Sound Active, and DMX modes.
• Single pixel control
• 4-button Digital Display for easy navigation
• Electronic Dimming 0 – 100%
• Flicker Free
• Temperature protection
Connections:
• Power connections: IP65 power in/out
• Power linking: Up to 12 units @ 120V ~ Up to 22 units @ 230V
• Data connections: 3-pin XLR in/out for DMX
Control:
• DMX Channels: 12/3/5/8/42/44CH
• Control modes: DMX, Auto, Sound-Active
• Menu: 4-digit LED display
Electrical:
• Power Consumption: 120W
• Input Voltage: 100-240V 50Hz/60Hz (Auto Sensing)
Physical:
• packing size: 1110x30x16mm (1pcs/carton)
• Gross weight: 9.8kg
