Super Hero 440 PRO is an advanced hybrid light, it is an very powerful beam light, the light beam is sharp and the minimum beam angle is just 2.5° . The narrow and dense light beam remains parallel even at very long distance. It is also a professional high power spotlight with a zoom from 4° to 50°, rotating gobos and fixed gobos, CMY color mixing, three color wheels, animation wheel, 2 prisms, “Auto focusing “ function, and smooth, fast and quiet movement. By using the separate frost filter, it’s a nice wash light too. Modular design easier the repairing and maintenance Super Hero 440 is a versatile fixture and can be used in any situation.
Major features:
Osram Sirius HRI 440W
4°- 50° electronic zoom (Spotlight mode)
2.5° beam angle (Beam mode)
CMY color mixing
Three color wheels with 14 color filters
2 CTO filters (3200 K and 2500 K) + 1 CTB filter
1 Wheel with 6 dichroic rotating gobos
1 Wheel with 18+1 fixed metal gobos
Animation disc
2 indexable rotating prisms (8-facet and linear 4-facet prism)
Frost filter for soft-edge projection
Electronic focusing
Auto focusing when zooming
Zooming and Auto-focusing at prism
0~100% dimmer
Speed adjustable strobe
Fast,smooth and quiet pan and tilt movements
Power will automatically decrease when light off or CMY closes
Modular design easier the repairing and maintenance
Art-Net
Technical Data:
POWER SUPPLIES
100~240V, AC 50/60Hz
Power consumption: 700W at 230V
LAMP SOURCE
Osram 440W
Color Temperature: 7800K
Life: 1500hrs
OPTICS
Beam angle: 2.5° ( Beam mode)
Zoom: 4°~50° (Spotlight mode)
Electronic focusing
Auto focusing
COLOR SYSTEM
CMY color mixing system
3 color wheels with 14 color filters
2 CTO filters(3200K and 2500K) + 1 CTB filter
Pre-set macros
GOBOS
1 wheel with 6 dichroic, indexable and interchangeable rotating gobos
1 wheel with 18+1 fixed metal gobos
Gobo-shake function
EFFECTS
Animation disc
2 indexable and interchangeable rotating prisms(8-facet and linear prism)
Zooming and Auto-focusing at prism
Independent frost filter
0~100% dimmer
Adjustable speed strobe effect
PAN/TILT MOVEMENT
Angle: Pan 540°, Tilt 240°
Fine resolution
Pan/Tilt three-phase motor driving
Automatic repositioning of Pan and Tilt after accidental movement
CONTROL AND PROGRAMMING
DMX Channel: 34
Protocol: DMX 512, Art-net
AUTO TEST function from MENU
Menu display LCD display
DMX Signal connection: 5-pin XLR input and output
2x Ethernet interface
ELECTRONICS
Self-charging battery, MENU edit available without main power connection
ON/OFF lamp control from light desk
Electronic monitoring with status error
Cooling system monitoring
Power will automatically decrease when light off or CMY closes
Dimensions / Weight:
• Dimensions: 66.7x44.8x38.6CM
• Weight:30kg
