D1 200RX 200W 5R Beam Moving Head

• Light Source: YODN MSD230 R7, 8000K.
• Beam Angle: 3°~10°.
• Stepper motors for quick, precise movement.
• Motorized focus and Power-Con In/Out.
• Frost filter to turn the hard edge beam to a wash.

Add to quote Next Product

 Optical:

• Light Source: YODN MSD230 R7, 8000K

• Light output: 770000 LUX @ 5M, 220000 LUX @ 10M (5-degree beam)

• Life Expectancy: 2,000 Hrs.

• Beam Angle: 3~ 10-degrees


Specifications:

• Colors: 14 colors plus white

• Gobos: 17 fixed gobos plus white

• Mechanical Dimming: 0% - 100%

• Shutter: Pulse effect; random strobe slow to fast
• Focus: motorized
• Frost: frost filter + wash effect
• Prism: 8-facet rotating prism

• Strobe: electronic/

• Strobe Rate: Strobe Rate: 0.75-24.5HZ


PAN/TILT

• Pan/Tilt: 540°/ 270°. Built-In Pan/Tilt Macros

• 16-Bit Pan/Tilt Positioning

• Stepper motors with micro stepping

• Rapid and extensive pan and tilt movements.


Connections:

• Power Input: Power-CON

• Data: 3pin DMX in/out


Control:

• Control Protocol: DMX 512
• DMX Channel Modes: 11/12/14 DMX Channels

• On Board: 4-Button LCD DMX display


Electrical:

• Power Consumption: 300W

• Multi-voltage: 100-240V, 50/60Hz


Dimensions / Weight:

• Dimensions: 40.5x34.5x47.5CM; 49x43x56CM/Carton

• Weight: 15.7kg(Net); 17kg(Gross)
